Home/ Products / CNC Milling Machine GV6050
CNC Milling Machine GV6050
The GV6050 high-speed heavy-duty CNC milling machine offers superior performance with its advanced Mitsubishi E80 control system, optional BT30 spindle, and high rigidity, making it ideal for demanding milling tasks in a range of applications including mold making and gantry milling.
Ningbo Kaibo CNC Machinery Co., Ltd. Ningbo, Zhejiang, China
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820134954/17产品high-speed-heavy-cutting-cnc-milling-machine-gv6050-1.png
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807135900/high-speed-heavy-cutting-cnc-milling-machine-gv6050-2.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807135900/high-speed-heavy-cutting-cnc-milling-machine-gv6050-3.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807135900/high-speed-heavy-cutting-cnc-milling-machine-gv6050-6.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807135900/high-speed-heavy-cutting-cnc-milling-machine-gv6050-5.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807135900/high-speed-heavy-cutting-cnc-milling-machine-gv6050-4.jpg
Recommended Products
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820135545/1产品dry-vacuum-graphite-machining-center-dc6060g-1.png
Dry Vacuum Graphite Machining Center DC6060G
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820135230/10产品4-axis-cnc-milling-machine-with-automatic-tool-changer-dc8070a-1.png
4-axis CNC Milling Machine DC8070A With Automatic Tool Changer
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820135317/7产品cnc-engraving-milling-machine-for-aluminum-dc6040d-1.png
Cnc Engraving Milling Machine For Aluminum Dc6040D
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820113751/28.png
Large Stroke VMC With Mitsubishi Controller Fh1890L
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820135436/4产品5-axis-shoe-last-cnc-milling-machine-dc6060a-1.png
5-axis Shoe Last CNC Milling Machine DC6060A
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820135256/8产品cnc-engraving-milling-machine-for--copper-electrode-dc6050a-1.png
Copper Electrode CNC Engraving And Milling Machine DC6050A
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820135525/1产品dry-vacuum-graphite-machining-center-dc6060g-1.png
Wet Graphite Machining Center DC6060G
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820134934/18产品double-column-large-cnc-milling-machine-gv1625-1.png
Double Column Large CNC Milling Machine GV1625
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820135211/11产品cnc-milling-machine-for-wheels-with-bt40-spindle-dc1090a-1.png
Wheel CNC Milling Machine DC1090A With BT40 Spindle
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820134505/27产品cnc-vertical--machining-center-with-gear-box-fh1580l-1.png
CNC Vertical Machining Center With Gearbox FH1580L
Product Parameters
Accuracy
positioning accuracy: 0.01 mm
Repeatability: 0.005 mm
See more
Workbench
working desk size: 610*600mm
T-slot dimensions: 5T-16-125 mm
weight capacity: 300 kg
Processing range
X/Y/Z axis travel: 600/500/260 mm
Gantry width: 700 mm
Beam to workbench: 500 mm
Distance from spindle nose to worktable: 130-390 mm
Door opening width: 650 mm
Feed
Maximum feed speed G00: 15 m/min
Maximum working speed G01: 10 m/min
X/Y/Z axis motor power: 850W/850W/850W
Spindle
Spindle motor power: 5.5 kW
Maximum spindle speed: 24000 rpm
Tool holder: ER25(φ3.17-φ16)
Spindle diameter: 125 mm
Common
Power supply and total capacity: 3P/380V/50Hz/12KVA
Machine weight: 4200 kg
aspect: 2200*1800*2200mm
Main components
Controller: Syntec21MA/Taiwan
AC servo motor (driver): Yaskawa/Japan
Spindle inverter: Innovation/China
Linear Guides: 30Hiwin, PMI/Taiwan
Ball Screw: 2810Hiwin,PMI/Taiwan
Electronic handwheel: EHDW-BA5S-1 Future/Taiwan
Lubrication system: YET-A2P2ISHAN/Taiwan
Oil coolant cooler: Parsonshal/China
air conditioner: Opt.Parsonthor/China
Pneumatic system: AirTac/Taiwan
Chip conveyor: -
Water tank capacity: 137 liters
Water pump power: 400W
Tool library (optional)
ATC Type: Inline/Arm Type
Air traffic control capabilities: 6 pieces/20 pieces
Close
Product Details
Product Introduction
High-speed heavy-duty cutting CNC milling machine GV6050 is a double-column vertical machining center designed for high-speed heavy-duty milling tasks.
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807135900/high-speed-heavy-cutting-cnc-milling-machine-gv6050-5.jpg
Advantages and features
1. Equipped with Mitsubishi E80 control system
2. Optional BT30 high-speed spindle
3. The cross-sectional area of ​​the bed is larger and the rigidity is higher
4. Increased spindle power, stronger milling capability
5. Z-axis travel is enlarged, and the processing range is larger
6. Improved door opening mechanism, more convenient for loading and unloading workpieces
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807135900/high-speed-heavy-cutting-cnc-milling-machine-gv6050-6.jpg
Application Scenario
1. Hypervisor
2. CNC gantry milling machine
3. Mould making machine
4. Graphite machine
5. Drum machine
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807135900/high-speed-heavy-cutting-cnc-milling-machine-gv6050-4.jpg
Ordering Information
Custom Request
Our products support customization!
Packing and shipping
Support wooden box packaging and vacuum tin foil packaging;
All packaging complies with ocean, truck and railway standards;
Payment method
COMM
COMM
L/C
L/C
T/T
T/T
A/P
A/P
O/A
O/A
D/P
D/P
D/A
D/A
Refunds
If there is any problem with the product, please contact us at the first time.
Corporate Information
Ningbo Kaibo CNC Machinery Co., Ltd.
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240731151209/安全生产标准化三级企业.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240731151209/ISO9001质量管理体系认证证书%202022.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240731151209/ISO9001Quality%20management%20system%20certificate%202022.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240731151209/ISO45001职业健康安全管理体系认证证书.jpg
100%
On-time delivery rate
Less than 3 hours
Response time
52000
Construction area
Service Guarantee
Service Information
Tel
+86-15805747758
Email
[email protected]
Address
Industry Area of ​​Changjie, Ninghai, Ningbo, Zhejiang, China
Call Now
Advisory Message
Pre-sales advice
Equipment can be customized according to your requirements (machine configuration, color...)
After-sales service
1. After-sales guarantee: We provide one-year free quality assurance service for the products we sell to ensure the stability and reliability of the products.
2. Technical support: The company has 26 sales service offices, equipped with professional technicians, who can answer customer questions online 24/7 and provide remote or on-site technical support.
3. Training service: Provide customers with free operation and maintenance training to ensure that customers can use and maintain the equipment proficiently.
4. Accessories supply: Provide original accessories for a long time to ensure the continuous and normal operation of customers' equipment.
5. Customer Feedback: Respond to customer feedback in a timely manner and continuously improve products and services to meet customer needs to the greatest extent possible.
Specific details
Please contact us
Product Specifications Reference
Spindle type
ER25/5.5kw/24000rpm electric spindle NBT30/5.5kw/24000-30000rpm electric spindle NBT30/7.5kw/24000-30000rpm electric spindle HSK E40/5.5-7.5kw/30000rpm electric spindle More spindles
Tool magazine type
Straight tool magazine (6 pieces) Arm type tool magazine (20 pieces)
